SKU
ZA K630147-FDHD
List price
$213.89
Price
$213.89

USA Standard Gear uses advanced alloys and the latest heat-treating technologies to produce a strong, durable axle. This kit contains all the components to replace, repair, or upgrade axle shafts so your vehicle will be up and running fast.

  • Fits Dana 80 Differential
  • Length 36.17 inch.
  • 37 Spline
  • Rear, Full Float Axle
  • 20 Tooth External Splined Flange
  • Advanced Heat-Treating Results in a Stronger, More Durable Axle

Features and Benefits:

  • Fits Dana 80 Differential
  • Length 36.17 inch.
  • 37 Spline
  • Rear, Full Float Axle
  • 20 Tooth External Splined Flange
  • Advanced Heat-Treating Results in a Stronger, More Durable Axle
Details:
  • AAP UDA 12:Ea
  • AAP UDA 22:1
  • AAP UDA 4:85
  • Inboard Spline Quantity:37
  • Retainer Included:no
  • Wheel Bolt Pattern Size:20 Tooth External Spline
Application Summary:

1992-2002 Chevrolet C3500HD (Rear) (Qualifier: Except Wide Track Axle / Note: Dana 80

  • Rear Axle Shaft (one side)
  • Full Floating Axle Shaft
  • 37 spline
  • 36.17 inch. Long mesured from inside of teeth
  • 20 Tooth External Splined Flange)
  • 1993-1996 Chevrolet P30 (Rear) (Qualifier: Except Wide Track Axle / Note: Dana 80
  • Rear Axle Shaft (one side)
  • Full Floating Axle Shaft
  • 37 spline
  • 36.17 inch. Long mesured from inside of teeth
  • 20 Tooth External Splined Flange)
  • 1992-2002 GMC C3500HD (Rear) (Qualifier: Except Wide Track Axle / Note: Dana 80
  • Rear Axle Shaft (one side)
  • Full Floating Axle Shaft
  • 37 spline
  • 36.17 inch. Long mesured from inside of teeth
  • 20 Tooth External Splined Flange)
  • 1993-1996 GMC P3500 (Rear) (Qualifier: Except Wide Track Axle / Note: Dana 80
  • Rear Axle Shaft (one side)
  • Full Floating Axle Shaft
  • 37 spline
  • 36.17 inch. Long mesured from inside of teeth
  • 20 Tooth External Splined Flange)
Vehicle Fitment
1992-2002 Chevrolet C3500HD
1992-2002 GMC C3500HD
1993-1996 Chevrolet P30
1993-1996 GMC P3500
Brand
USA Standard Gear
Category
Drivetrain & Differentials
Differential
Axle
Axle Shafts
Specs
Country of Origin: IN
Sold As: Kit
Position: Rear
UPC: 883584119579
Availability: Available
Universal: No
Vehicle Type
Truck/SUV
Core Charge
$0.00
